GS10/GS15, Operation

flashing yellow less than four satellites are tracked, a position is

not yet available.

yellow a navigated position is available.

flashing green a code-only position is available.

green a fixed RTK position is available.

Power LED

(active

battery

)

off battery is not connected, flat or GS10/GS15 is

switched off.

green power is 40% - 100%.

yellow power is 20% - 40%. The remaining time for

which enough power is available depends on the

type of survey, the temperature and the age of

the battery.

red power is 5% - 20%.

fast flashing red power is low (<5%).

Power LED

(passive

battery

)

off battery is not connected, flat or the GS10/GS15

is switched off.

IF the is THEN
