40

GS10/GS15, Operation

3.2.2 Battery for GS10

Change battery

step-by-step

Step Description

)

The batteries are inserted in the front of the instrument.

1. Loosen the screw of one of the battery compartments.

2. Open the cover of the battery compartment.

3. With the Leica logo facing upwards, slide the battery into the battery

compartment and push upwards so that it locks into position.

GS_083

2

3

3

1
