Chapter 2 - Configuration
Configuration 3 Composite Link Configuration
Local Channel Parameter
STP FLOW ENQ/ PASS PASS
CHN SPD WORD BIT PARITY CONTROL ACK ECHO PACE EIA XON
01 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
02 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
03 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
04 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
05 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
06 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
07 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
08 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
OK
Configuration 3 Local Site Channel Parameters
Local Channel Parameter
STP FLOW ENQ/ PASS PASS
CHN SPD WORD BIT PARITY CONTROL ACK ECHO PACE EIA XON
01 19200 8 1 NONE XON/XOFF OFF OFF XON OFF OFF
02 19200 8 1 NONE XON/XOFF OFF OFF XON OFF OFF
03 19200 8 1 NONE XON/XOFF OFF OFF XON OFF OFF
04 19200 8 1 NONE XON/XOFF OFF OFF XON OFF OFF
05 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
06 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
07 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
08 19200 8 1 NONE XON/XOFF OFF OFF OFF OFF OFF
OK
